Products Description

The lugagge design makes the laser cleaning machine easy to move and operate, and is convenient for customers to use and store in different workplaces. Using high-performance optical devices and advanced laser technology, it can efficiently and quickly remove dirt and cleaning layers on the surface of various materials, which can not only improve the cleaning effect, but also greatly shorten the cleaning time.

This Gaussian laser cleaning machine has three power options: 200w and 300w.



Specification

Model	QYCL-FP200	QYCL-FP300
Average laser power (w)	200	300
Single pulse energy (mj)	1.8
Rated power (kw)	0.8	1.1
Power adjustment range (%)	10-100
Width of scanning (mm)	100*100
Focal distance (mm)	160/210/330/420
Central wavelength (nm)	1060-1070
Cooling method	Air Cooling
Fiber length (m)	5m
Type of laser source	Pulsed fiber laser
Dimension of machine (mm)	500 X 438 X302
Weight of machine (kg)	19
Power supply	220V / 110V

We also offer 500w and 1000w Gaussian beam pulse laser cleaning machines, please click here for details.



Advantages

1. Gaussian beam precision control

▶Energy distribution optimization: Gaussian distribution beam is used, and the energy concentration is increased by 40% compared with flat top beam, achieving micron-level precision cleaning.

▶Zero substrate damage: The heat affected zone is controlled to <5μm through beam shaping technology, ensuring that the surface of precision parts such as aluminum alloy/composite materials is scratch-free.



2. High-quality core components

▶MAX/Raycus/JPT/IPG famous brands laser, 100,000 hours of life.

▶Schneider/Omron/Chint first-line electrical appliance brands, safe and stable.



3. Intelligent cleaning head system

▶8 scanning graphics: rectangle/spiral/circle and other modes.
▶Safety lock: No light will be emitted after the dust cover is closed.
▶Tilt protection: No light will be emitted when the tilt angle exceeds the limit to prevent accidental injury.
▶Focus assist: Accurately locate the focal length.



Application

Facade Cleaning Bricks, monuments, sandstone and similar materials can be cleaned "as new".	Wood Cleaning Renovation of furniture, paint removal from wood and antiques restoration all can be done with your cleaning technique.	After-Fire Cleaning Soot removal after fires, cleaning buildings interiors and constructions suffered of fire.
Art And Heritage Conservation Restoration and conservation of art and cultural heritage is always exciting.	Food Industry Cleaning Cleaning heavy grease, burnt food,maintenance and service for food production.	Oil And Gas Turbine cleaning, NDT preparation, weld cleaning, coating removal and many more.



FAQ

1: What Types Of Products Do You Have?
We mainly sell four types of laser products: laser cleaning machine, laser welding machine, laser cladding machine, and laser cutting machine.

2: How Do I Choose The Most Suitable Machine For Me?
You can tell us your specific needs: industry, materials, photos, etc. - Do you have a purchase budget? Do you need pre-sales proofing test? We will recommend the most suitable products to you according to your budget and clear requirements.

3: This Is My First Time To Buy This Kind Of Machine. Is It Easy To Use?
The operation is very simple. Most of our customers mastered the use skills within one single hour. We will send you the english version(language is customizing) of user manual and operation guiding video, as well as we can train you through remote online video chatting.

4: How Do You Guarantee The Quality Of The Goods?
Each equipment of us shall experience a strict quality inspection and long-time continuously running test(72 hours) before shipping out. We provide inspection videos or photos for customer to confirm the cleaning/welding/cladding/cutting effects and performance of our machine. Quality certificate and warranty card will be sent along with the package.
