High quality laser cleaning solution service for the world.
The suitcase type portable laser cleaning machine is an efficient and convenient cleaning tool. It can quickly remove dirt and oxide layers on the surface of the workpiece under the action of a high-speed rotating laser beam, restoring it to its original luster and finish.
Suitcase portable laser cleaning machines can be used in a variety of industrial fields, such as aerospace, automobiles, machinery, electronics, etc., and can clean workpieces of various materials, such as metals, ceramics, plastics, etc.
Specification
|
Model |
QYCL-FP50D |
QYCL-FP100D |
QYCL-FP200D |
|
Laser power (w) |
50 |
100 |
200 |
|
Single pulse energy (mj) |
1.1 |
1.6 |
1.6 |
|
Weight of hand-held head (kg) |
1 |
||
|
Power adjustment range (%) |
10-100 |
||
|
Width of scanning (mm) |
100*100 |
||
|
Focal length (mm) |
100/160/260 |
||
|
Central wavelength (nm) |
1060~1070 |
||
|
Cooling method |
Air Cooling |
||
|
Fiber length (m) |
3 |
||
|
Type of laser source |
Pulsed fiber laser |
||
|
Dimension of machine (mm) |
315*152*275 |
394*160*275 |
405*200*260 |
|
Weight of machine (kg) |
8.5±0.5 |
11±0.5 |
16±0.5 |
|
Power supply |
220V |
||
Details
|
Suitcase structure design Small size, light, easy to carry, battery/external power supply two modes can be selected freely, it's not only suitable for small spaces, high altitude, field operations, etc., but also suitable for factory workshop operations. |
|
|
|
Portable cleaning terminal Two-dimensional galvanometer structure, multi-pattern cleaning solution, small cleaning head is small and light, timely alarm, safe and reliable. |
|
Open functional design Visual multi-language touch control screen, equipped with a variety of industrial bus communication protocol interface to real-time monitoring of the control system status, help users quickly locate and solve problems. |
|
Company Profile
Shandong Qiangyuan Laser of SDIIT Ltd. (SDQY Laser) founded by Laser Institute of Shandong Academy of Science since 1978. A leading enterprise focusing on the R&D, manufacturing, sales and service of laser cleaning, welding, cutting, cladding machines and solutions.
Our products has exported to European, American, Middle Eastern, Australian, African countries and regions, we provided customers with high quality laser solutions. The professional quality and service in the laser industry market have establish a good brand image and reputation.
50w 100w 200w Suitcase Type Pulse Laser Cleaning Machine
